1~3kV交聯聚乙烯絕緣電力電纜
本產品適用于輸配電線路作配送電能之用。常用于城市的地下電網、發電站的引出線路、企業內部供電。室內可采用支架、托架、梯架或電纜夾具明敷;室外可采用電纜溝、隧道或直埋敷設。
我公司生產的交聯聚乙烯絕緣電力電纜產品分為非阻燃、阻燃、耐火全系列。也可根據用戶需要,設計制造具有耐低溫、阻水、防白蟻、防鼠等某些特殊要求的交聯電纜。
阻燃電纜包括含鹵阻燃阻燃電纜和無鹵阻燃電纜,兩種阻燃電纜均能有效阻止火勢的蔓延,用戶可根據使用環境的不同選用。含鹵阻燃電纜適用于戶外、人員密度較小的場合。無鹵阻燃電纜燃燒時釋放煙霧量小且無毒,便于火災情況下的人員疏散,適用于軌道交通沿線、區間隧道、車站、設備安裝、消防建設,同時也可用于人員密集的高層建筑、商場、劇院、發電站、化學工廠、碼頭、港口、城市廣場等重要社會公共場合。
Low voltage XLPE insulated power cables are used for power distribution system with rated voltage of 0.6/1kV and 1.8/3kV. Suitable for fixed installations, indoor and outdoor, in free air, for direct burial, in duct, trench, shaft, cable trays and ladders, etc..
執行標準:
本品按GB/T 12706.1組織生產0.6/1kV和1.8/3kV交聯聚乙烯絕緣電力電纜,同時還可根據用戶需要按國際電工委員會推薦標準IEC、英國標準、德國標準及美國標準生產。
GB/T 12706.1, IEC60502-1, BS5467, AS/NZS 5000.1, or other standards on request.
型號 Type |
額定電壓/kV Rated voltage(kV) |
名稱 Description |
YJV | 0.6/1 1.8/3 |
銅芯交聯聚乙烯絕緣聚氯乙烯護套電力電纜 Copper conductor XLPE insulated PVC -sheathed power cable |
YJV62 | 銅芯交聯聚乙烯絕緣非磁性金屬帶鎧裝聚氯乙烯護套電力電纜 Copper conductor XLPE insulated, non-magnetic metal tape armoured PVC-sheathed power cable |
|
YJV22 | 銅芯交聯聚乙烯絕緣雙鋼帶鎧裝聚氯乙烯護套電力電纜 Copper conductor XLPE insulated, steel tape armoured PVC-sheathed power cable |
|
YJY | 銅芯交聯聚乙烯絕緣聚烯烴護套電力電纜 Copper conductor XLPE insulated PO -sheathed power cable |
|
YJY63 | 銅芯交聯聚乙烯絕緣非磁性金屬帶鎧裝聚烯烴護套電力電纜 Copper conductor XLPE insulated, non-magnetic metal tape armoured PO-sheathed power cable |
|
YJY23 | 銅芯交聯聚乙烯絕緣雙鋼帶鎧裝聚烯烴護套電力電纜 Copper conductor XLPE insulated, steel tape armoured PO-sheathed power cable |
|
YJLV | 鋁芯交聯聚乙烯絕緣聚氯乙烯護套電力電纜 Al- conductor XLPE insulated PVC -sheathed power cable |
|
YJLV62 | 鋁芯交聯聚乙烯絕緣非磁性金屬帶鎧裝聚氯乙烯護套電力電纜 Al-conductor XLPE insulated, non-magnetic metal tape armoured PVC-sheathed power cable |
|
YJLV22 | 鋁芯交聯聚乙烯絕緣雙鋼帶鎧裝聚氯乙烯護套電力電纜 Al-conductor XLPE insulated, steel tape armoured PVC-sheathed power cable |
|
YJLY | 鋁芯交聯聚乙烯絕緣聚烯烴護套電力電纜 Al-conductor XLPE insulated PO -sheathed power cable |
|
YJLY63 | 鋁芯交聯聚乙烯絕緣非磁性金屬帶鎧裝聚烯烴護套電力電纜 Al-conductor XLPE insulated, non-magnetic metal tape armoured PO-sheathed power cable |
|
YJLY23 | 鋁芯交聯聚乙烯絕緣雙鋼帶鎧裝聚烯烴護套電力電纜 Al-conductor XLPE insulated, steel tape armoured PO-sheathed power cable |
|
注:我公司同時生產以上型號電纜阻燃產品,阻燃電纜在前面加阻燃標識。 Note: Our company also produces flame-retardant products of the above types of cables, and the flame retardant cables are marked with flame-retardant labels on the front. 阻燃:ZA—、ZB—、ZC—、ZR—、ZR-IVC—、WDZ—、WDZA—、WDZB—、WDZC— 耐火:N—、NH—、NH-IVB— 阻燃耐火:ZAN—、ZBN—、ZCN—、WDZN—、WDZAN—、WDZBN—、WDZCN— |
